編碼規則
|
E |
S |
3 |
¾ |
0 |
2 |
C |
G |
6 |
9 |
4 |
1 |
|
|
1 |
2 |
3 |
¾ |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
編碼 |
詳細說明 |
|
1 |
應用型式 |
E |
增量型Increment |
|
M |
伺服馬達專用型Motor |
|
A |
絕對位置型Absolute |
|
2 |
出力軸型式 |
S |
出力軸Shaft |
|
H |
中空軸 Hollow |
|
T |
貫穿軸 Through hole |
|
3 |
編碼器外徑 |
3 |
37mm |
5 |
52mm |
|
4 |
解析度ppr |
01 |
100ppr |
11 |
1024ppr |
40 |
4000ppr |
|
02 |
200ppr |
12 |
1200ppr |
50 |
5000ppr |
|
03 |
300ppr |
15 |
1500ppr |
60 |
6000ppr |
|
0C |
360ppr |
20 |
2000ppr |
72 |
7200ppr |
|
05 |
500ppr |
21 |
2048ppr |
82 |
8192ppr |
|
06 |
600ppr |
25 |
2500ppr |
90 |
9000ppr |
|
10 |
1000ppr |
30 |
3000ppr |
99 |
10000ppr |
|
5 |
電氣輸出 |
V |
電壓輸出型 Voltage Output |
|
C |
開集極輸出 Open Collector |
|
L |
線驅動 Line Driver |
|
P |
推挽式 Push Pull |
|
6 |
Z相輸出型式 |
G |
gated with A&B |
|
N |
non-gated |
|
7 |
出力軸內外徑 |
6 |
6mm |
|
8 |
8mm |
|
8 |
編碼器電源 |
5 |
5V |
|
8 |
5~12V |
|
9 |
7~24V |
|
9 |
操作環境 |
4 |
IP40 & 80oC |
A |
IP40 & 100oC |
|
5 |
IP50 & 80oC |
B |
IP50 & 100oC |
|
6 |
IP65 & 80oC
|
|
|
