| Specifications |
Model No.
|
SMK-420
|
Ports Switch for PC
|
VGA D-Sub 15 pin, Keyboard PS/2 6 pin, Mouse PS/2 6 pin
|
Weight
|
Single port: 11kgs (28lb)
8/16 ports: 11.5 kgs (29.2lb)
|
Dimension (W x H x D)
|
17.42" x 1.75" x 20.0"
(442.4mm x 44.0mm x 508.0mm) |
Power Supply
|
100/220V auto switching, 50W
|
Size
|
1U 19" Rackmount Type
|
* Extension Cable
|
None
|
* Extension Rail
|
Up to 35.4" (900mm)
|
* Construction Material
|
Industrial Metal
|
Keyboard
|
105 key, notebook type
|
Mouse
|
Touchpad
|
Color
|
Black |
| Protection |
Front panel with Thumb screw
Rail with self-locking device
LCD back-light will be turned-off when
the screen set is turned down |
| * KVM Switch |
Build-in 8(480) or 16(490) ports KVM Switch
|
* Security Lock
|
Thumb screw x 2
|
Operation Temperature
|
0-50?C (32-122癋)
|
|
|
| Display |
Diagonal
|
15" (16:9) 17" (16:9)
|
| LCD Resolution |
1280 (X3 ) x 768 |
| Contrast Ratio |
350:1 600:1 |
| Brightness |
450 nits |
Frequency
|
80Hz |
Frame Rate
|
16.2M colors, OSD |
LTCFL
|
CCFL life Time 35,000 hr. | | |
