| Specification |
Model No.
|
DMK-520
|
Size
|
1U 19" Rackmount type
|
Construction
|
Heavy duty steel
|
Keyboard
|
105 key, notebook type Multi-language: US, RU, GR, FR, UK, IT, KR, CH |
Mouse
|
Touchpad |
Dimension
|
17.417" x 1.736" x 18.903" 442.4mm x 44mm x 480mm |
Weight
|
12kg (26.5 lbs) |
Power Supply
|
Industrial level AC 100/240V Auto Switching |
| Protection |
Tempered glass protection to the LCD screen |
Auto Power Switch
|
LCD back-light will be turned off when the screen is turned down |
| Operating Temp. |
0-50癈 (32-122癋) |
Folding Angle
|
Up to 110?/td> |
Extension Length
|
431.8mm (17") |
|
Drawer Design
|
Dual rails for panel and keyboard enables independent extraction of either panel or keyboard alone |
|
KVM Interface |
VGA DB 15pin, PS/2 Keyboard mini Din 6 pinPS/2 Mouse mini Din 6 pin |
| LCD |
17" TFT LCD, 1280*1024, with 300 nits brightness,160/160 viewing angle, contrast ratio 450:1
|
Certification
|
CE, FCC
|
|
|
| Display |
Diagonal
|
17" TFT LCD |
| Resolution |
1280 x 1024 |
| Display Area |
337.9mm x 270.3mm |
| Contrast Ratio |
450:1 |
Brightness
|
300 nits
|
Viewing Angle
|
160/160 |
Frequency
|
60Hz
|
Color
|
16.2M colors |
Control System
|
Auto adjustment, brightness, contrast, H-V position, frequency, size, and display mode |
LCD Cell Life Time
|
Lcell, Min. 50,000 Hrs. , MTBF based |
|
|
|
Min. |
Typ. |
Viewing Angle
|
Horizontal |
(70) |
(80) |
| Vertical |
Response Time
|
TR |
none |
(5) |
| TF |
(11 | | | | |
